CPU: Intel Atom D2550 GPU 1.86GHz/1MB
芯片組： Intel NM10
內存:204Pin DDR3 SO-DIMM
I/O端口: 1*LINE OUT&MIC,6*USB,2*LAN,1*HDMI,1*VGA,1*KB/MS
串口: 2*RS-232,1*RS-232/485,3*RS-232/422/485
看門狗: 256級,可編程時間到中斷、時間到系統復位
存儲: 1*2.5"SATA盤位
擴展槽: 無
擴展總線：1個mPCIEx1或mSATA接口
電源: DC_IN 12~24V
尺寸: 246*209*63mm(W*D*H)
Processor System
CPU
Intel Atom 1.86GHz/1MB D2550 GPU
Chipset
Intel CG82NM10(NM10)
BIOS
32Mb AMI BIOS
Memory
Max. Capacity
4GB DDR3 Memory installed (up to 4.0GB Max. Capacity )
Socket
1*204Pin DDR3 SO-DIMM
Graphics
Controller
Intel HD Graphics
Ethernet
LAN
2*10/100/1000 Mbps Ethernet Controller, Support PXE/WOL
Audio
Interface
HD Audio ,1*Line-out, 1* Mic-in
Storage
HDD
1 x SATA HDD Bay for 2.5"
1 x mSATA
Expansion Slot
NO
No
External I/O Interface
Serial Port
2*RS-232, 1*RS-232/485, 3*RS-232/422/485
USB
6*USB
Audio
1*LINE OUT & MIC
LAN
2*RJ45
KB/MS
1*PS/2
Display
1*VGA, 1*HDMI
Watchdog
Watchdog timer
Programmable 256 levels timer interval, setup by software
Power Requirements
Power Input Votage
DC_IN 12~24V
Power Adapter
AC-to-DC Adapter, DC12V/5A 60W (Optional),with DC Jack Plug
Power cable
With plug USA type/ Europe type/UK type (by requirement)
Software Support
Microsoft Windows
XP,Win7/8/10，windows 2008
Linux
Support (by project)
General
Dimensions (W x Dx H)
246 x 209 x 63mm
Case Colour
Iron gray
Mounting
Stand/ Wall
Enclosure
Aluminum Housing
Thermal Solution
Fanless
Environment
Operating Temperature
-20 ~ 60°C
Storage Temperature
-40 ~ 80°C
Relative Humidity
5~ 95% (non-condensing)
