詳細信息
CPU: 板載 Intel Atom D525 GPU
芯片組: Intel 82801+ICH8-M
內(nèi)存: 板載2.0GB DDR3 System Memory
I/O端口：2*RJ45、1*VGA、1*Audio、4*USB、1*SIM、1*HDMI
串口：2*RS-232、1*RS-232/485、3*RS-232/422/485
看門狗：256級，可編程時間到中斷、時間到系統(tǒng)復(fù)位
存儲空間：1*2.5"SATA盤位,1*CF槽位(可選購）
擴展槽位：1個PCI/PCIE 擴展槽位，1x mPCIE槽位
輸入電源：DC_12~24V
產(chǎn)品尺寸：195 x 205 x 96 mm（WxDxH)
| Processor System | CPU | Intel Atom® Processor D525 (1M Cache, 1.80 Ghz) |
| Chipset | Intel® 82801HBM(ICH8-M) | |
| BIOS | 8Mb AMI BIOS | |
| Memory | Max. Capacity | On-board 2GB DDR3 Memory |
| Graphics | Controller | Intel®GMA3150 |
| Ethernet | LAN | 2*10/100/1000 Mbps Ethernet Controller, Support PXE/WOL |
| Audio | Interface | HD Audio ,1*Line-out, 1* Mic-in |
| Storage | HDD | 1 x SATA HDD Bay for 2.5" |
| 1 x mSATA | ||
| 1*CF Slot (Optional) | ||
| Expansion Slot | PCI | 1*PCI Slot |
| MiniPCIE | 1*Mini PCI-E X1 | |
| External I/O Interface | Serial Port | 2*RS-232, 1*RS-232/485, 3*RS-232/422/485 |
| SIM | 1*SIM Slot (Optional) | |
| USB | 4*USB | |
| Audio | 1*LINE OUT & MIC | |
| LAN | 2*RJ45 | |
| Display | 1*VGA, 1*HDMI | |
| Watchdog | Watchdog timer | Programmable 256 levels timer interval, setup by software |
| Power Requirements | Power Input Votage | DC_IN 12~24V |
| Power Adapter | AC-to-DC Adapter, DC12V/7.5A 90W (Optional),with DC Jack Plug | |
| Power cable | With plug USA type/ Europe type/UK type (by requirement) | |
| Software Support | Microsoft Windows | XP,Win7/8/10，windows 2008 |
| Linux | Support (by project) | |
| General | Dimensions (W x Dx H) | 195 x 209 x 96mm |
| Case Colour | Iron gray | |
| Mounting | Stand/ Wall | |
| Enclosure | Aluminum Housing | |
| Thermal Solution | Fanless | |
| Environment | Operating Temperature | -20 ~ 60°C |
| Storage Temperature | -40 ~ 80°C | |
| Relative Humidity | 5~ 95% (non-condensing) |
