BASIC INFO
| Category | Attribute | Value |
| System Hardware | Processor | Intel® Core? i7-6700HQ/i7-7920HQ Processor (6M Cache, up to 3.50 Ghz) |
| BIOS | 8Mb AMI SPI | |
| Chipset | Intel HM170 | |
| Memory | 2*260 Pin DDR4 SO-DIMM socket,(up to 32GB Max. Capacity ) | |
| Storage | One Drive Bay for SATA 2.5" HDD, 1*mSATA slot, 1*7Pin SATA port | |
| Watchdog Timer | Programmable 256 levels timer interval，setup by software | |
| Audio | Intel HD Audio, LINE OUT & MIC-IN | |
| Ethernet | 4*10/100/1000 Mbps Ethernet Controller | |
| Graphics Engine | Intel® HD Graphics | |
| External I/O Interface | Ethernet (RJ-45) | 4*Intel I211-AT (10/100/1000 Mbps Ethernet Controller) |
| Audio | 1*LINE OUT & MIC-IN | |
| USB Port | 4*USB3.0, 6*USB2.0 | |
| Display | 1*HDMI , 1*VGA | |
| KB/MS | 1*KB/MS | |
| LPT | 1*LPT | |
| Serial Port | 6*RS-232, 2*RS-232/485, 2*RS-232/422/485 | |
| PWR | 1*PWR, 1*RST | |
| General | Power Input Votage | DC_IN 12V~24V |
| Power Adapter | AC to DC, DC12V 120W (Optional) | |
| Expansion | 1*mPCIE,1*164Pin MINI PCIEx16 | |
| 3*PCI slot (1*PCIe x4 and 2*PCI Optional ) | ||
| Dimensions (W x Dx H) | 263 x 246 x 153 mm | |
| Colour | Iron gray | |
| Mounting | Stand/ Wall | |
| Enclosure | Aluminum Housing | |
| Thermal Solution | Fanless | |
| Environment | Operating Temperature | -20 ~ 60°C |
| Storage Temperature | -40 ~ 80°C | |
| Relative Humidity | 5~ 95% (non-condensing) |
